Reactor&Mixing Machine 5
Reactor&Mixing Machine 5
  • Product Details

Model description:
This is a our advantage product! Dispersion, grinding, mixing process of the integration of production equipment. Applicable to the mucilage/paste, paint, pigment, dyestuff, printing ink, pharmaceutical, cosmetics and other industries.




Technology advantage:
Low innovative will be dispersed, mixing, grinding, or dispersing, mixing, high shear emulsification) three types of process integration for the integration of the whole equipment.

Low can quickly improve product quality and production efficiency.



Low owns two patents basket mill, can make products quickly to achieve the effect of fine! The grinding performance, durable performance is one of the best equipment!

Low precision manufacturing the connection of the frame and the main shaft, processing precision ≦ 0.02 mm; Beyond the imagination of high-speed stability!

Low mechanical seal with the function of automatic circulation lubrication, cooling, in high speed 1450 r/min can still bring effective sealing performance and significantly prolong durability.



Low self r&d manufacturing large tanks polishing equipment for polishing effect to finish: 4 k / 25 asurgeon, than most sand machine polishing effect.


* all stainless steel parts are all manual argon arc welding technique, no leakage, cracking and other weld defects.


Working principle:


1. The raw materials (liquid can be pumped or vacuum suction form) into disperse/grinding one kettle;


2. In the distributor can be opened in the process of medium and low speed dispersion mixing;


3. After all the raw materials into the distributor will rotate speed adjustment to the highest speed to disperse/shear performance to achieve the best effect;


4. After fully premixed open material basket mill, adjust the speed according to the characteristics of material and product requirement and open stop time;


5. Product by the dispersion/grinding, mixing, fine effect after the pump or vacuum suction form into the multifunctional kettle; Midway through into the pipeline can be equipped with bag filter and other filter equipment.


6. The material into the multifunctional kettle, adding other materials (such as thickening agent, etc.), by opening one of the group of low speed mixer (can be equipped with scraping wall) and two sets of high speed disperser, strong hybrid force applied materials, can express to effect;


7. The equipment design pressure is 0.1 ~ 0.4 Mpa, can be equipped with vacuum pump for vacuum deaeration processing materials; After the completion of the production of viscous material can be pressurized discharge!


8. Equipped with automatic filling machine, can greatly reduce the labor intensity, improve the filling efficiency and accuracy.
