JHAO-DM Vertical Sand Mill
JHAO-DM Vertical Sand Mill
  • Product Details

Technical Features:
▪With professional and precise drive construction, the machine runs smoothly with little vibration and low noise
▪Grinding disc and balance wheel are made of alloy steel, with high hardness and good wear resistance
▪Optimization design of unilateral feeding valve ,in order to prevent the material and grinding media flow backward
▪Equipped with imported pneumatic diaphragm pump (Ingersoll-Rand), and the feeding speed could be adjusted
▪High efficiency for continuous production, good heat dissipation, convenient for color changing and cleaning



Main Technical Paramete :

Model

DMK10-1K10-1

DM20-1

DMK40-1

DMK80-2A

Volume of Barrel (L)

10

20

40

80

Main Power (kw)

5.5

11

18.5

30

Feeding Way (kw)

Pneumatic diaphragm pump

Dispersing Axis Apeed (r/min)

1450

1250

1000

850

Pump Flow Regulating Range (L/min)

2-12

2-12

2-12

3-24

Material Viscosity (pas.s)

<2

Max Production Volume (kg/h)

200

400

700

12000

Particle Size (um)

1-20

Weight (kg)

550

1200

1500

2000
